Wireless Remote VFD Radio Control – 900mhz

This kit, P/N A3A4821C, is comprised of the following parts:

A3A4822A Five-button MICRO transmitter, pre-synchronized to the receiver, including internal rechargeable lithium polymer batteries that charge over a micro USB connection.

A3A4823B Programmable four-output MICRO receiver, user-configurable (requires 4/8 button transmitter) as 1, 2, or 3 outputs in any combination of momentary or maintained outputs plus programmable “dump” output on the 4th output.

also see: Wireless Remote VFD Radio Control 2.4GHz

Description

This simple VFD remote control adds wireless to your VFD speed control. Using a small, keyfob-sized, but highly ruggedized transmitter, we give you control over direction, start/stop, and VFD speed.

The VFD radio remote steps through ten speeds latches the reverse output ON, and has an N/O output for start that is ON in start/run mode.

The receiver runs off of 9 – 30VDC (and draws 26 – 34mA if you’re powering the radio from the VFD supply), but you need a minimum of 12VDC to get the full 0 – 10V for the VFD speed controller.

The transmitter for the wireless VFD system runs off of internal lithium batteries that recharge over micro USB, and the system provides a nominal 300′ range.

Variable Frequency Drive sold separately

Features

RUGGED SYSTEMS Remote control systems built to last in harsh mobile hydraulic environments.	LICENSE-FREE/LONG RANGE Up to 1000′, 2.4GHz for worldwide use.
AC/DC Systems are available for both AC and DC applications.	BUILT TO LAST Heavy-duty, sealed components are used throughout.
TWO-WAY RADIO See what’s happening on the machine at your bellypack in real time.	CUSTOM BRANDING Get your remote with YOUR look and feel – even on a one-off.
