Description
Note: Please check downloads for Pump Boss II or Pump Boss III
Protection
IP65 OCU / IP66 MCU
Housing Material
High-impact, fiber-reinforced nylon OCU / Rugged aluminum MCU
Interface
Single CANbus interface that supports J1939 and CANopen
Long Life Switches
Switches are measured in millions of cycles
Power Supply
9-36 VDC 20W
Operating Range
600 ft / 180 m (2.4 GHz)
Closed Box Configuration
Wireless configuration of frequency and function enables simple and rapid deployment of spares
Digital Outputs
Eight solid state outputs 2 x 10A, 6 x 4A in a Category PL-d configuration
PL-d Safety Level
PL-d Safety level in compliance with ISO 13849
Accessory
Includes a leather holster for portability
Warranty
Standard one-year product warranty
ISO Certification
Manufactured in an ISO 9001:2015 certified operation
Options:
Rechargeable Battery – Drop-in cradle with power adapter and LiPo rechargeable batteries
Antenna – Chassis mount and line kit or magnet mount and line kit
