Description
With its small size (only 35 mm deep), N1030T is a PID controller with high performance, perfect for applications that have a limited amount of space and require practicality and cost reduction.
Besides its small size, N1030T has a detachable connector and an easy connector system for electrical connection, features that reduce installation time. The device accepts Pt100 and J/K/T thermocouples, has 2 independent timers, several operation modes, and it is possible to use only one output or combined action of its features.
Nowadays, given its versatility and accuracy, NOVUS N1030T is marketed to machine manufacturers from the most varied market segments.
– Single Loop PID and ON/OFF controller
– PID auto tuning
– Two independent outputs available
– Dual relay output or 1 pulse and 1 relay versions
– Six alarm functions: LO, HI, differential, differential LO, differential HI, sensor break
– Initial blocking alarm function
– Adjustable alarm hysteresis
– Thermocouples J, K, T and Pt100 input
– Temperature unit °C or °F
– Decimal place indication
– Configurable setpoints limits
– Password protected configuration
– Increasing or decreasing timer counters
– Timer time base in seconds or minutes
– Adjustable timer up to 99:59 (mm:ss or hh:mm)
– Timer trigger by setpoint or F key
– Control output linked to timer can turn on or turn off at end of timer interval
– Factory configuration parameters recovery
– Dual red and green four-digit display
– Front panel material PC UL94 V-2
– Enclosure material: PC UL94 V-2
– Front panel protecion: IP65
– Operating environment: 0 to 60 ºC, 20 to 80 % RH
– Dimensions: 48 x 48 x 35 mm, 1/16 DIN
– Power supply: 100 to 240 Vac/dc or 12 to 24 Vdc / 24 Vdc/ac
– Detachable terminal block
