Description
CBMCU is a machine control unit for radio remote control systems that enables operators to control complex and dangerous machinery safely with an ISO13849 PL-d safety rating on digital and CAN outputs. The system is built to handle demanding mobile applications.
The dual CAN bus interface supports J1939, CANopen, and CANopen Safety protocols. Closed-box configuration, programming,g and analytics can be performed. The PL-d safety level is based on black channel communications for control and feedback and a redundant dual-processor architecture. CattronLink™ wireless programming tool streamlines the management of your remote control system for firmware updates, updating configuration parameters, and monitoring device status.
Features:
Protection
IP66 – Read about IP ratings
Housing
Robust aluminum fully shielded enclosure for high EMI environments
Frequency Range
License exempt: 915MHz, 433MHz, 868MHz, 2.4GHz, licensed 450-470MHz
Interface
Dual CAN bus interface that supports CANopen, CANopen Safety, and J1939 protocols
Closed Box Configuration
Wireless configuration, programming,g and analytics
Black Channel Communication
PL-d safety level based on black channel telegram for both control and feedback, and a redundant dual-processor architecture
CattronLink Management Software
CattronLink enables continuous performance and simplifies configuration and feature upgrades
Diagnostics Data Collection
Data logging and diagnostics memory are logged on the MCU and available
Power Supply
9-36 VDC 20W
Digital Outputs
Eight PL-d outputs
PL-d Safety Level
PL-d Safety level in compliance with ISO 13849
ISO Certification
Manufactured in an ISO 9001:2015 certified operation
