Description
Heavy-duty replaceable relays and on-board fuse. These come factory preset to use the frequency of your generator’s AC output as a speed signal to disconnect the starter motor and shut the engine down on over-speed. For 24-volt operation, you must replace the 2 on-board 12V relays with 2 of these 24V relays! (identical to AS52 Model)
Works with 2-wire remote start applications as found in most automatic transfer switches.
Autostart
Configurable start and stop events
Zero Speed Restart
Zero-speed restart prevents starter pinion wear
Timer
Multi-function timer output for preheat, slow, airgate, and choke. Includes warm-up timer output
Relays
20A removable relays and a fuse eliminate slave relays and external fusing in most installations (fuel/crank circuits are rated 20A combined)
Lost Signal
Detects lost speed signal
Field Settings
Field settings with potentiometers and DIP switches
Set-Up Mode
Set up mode for quick calibration
Mounting
Industry-standard mounting configuration
ISO Certification
Manufactured in an ISO 9001:2015 certified operation
Options
Preset Calibration
Preset calibration with a fixed setting to prevent tampering
Heat Functions
Mid-heat and post-heat functions (during and after cranking)
Inputs
Momentary inputs for multiple start/stop locations. Inputs for photocell start/stop control
Call Control
Pull/hold call control for the fuel solenoid
